304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety

304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety
304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety
304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety 304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety 304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety 304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety

Large Image :  304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety

Product Details:
Place of Origin: Beijing, China
Brand Name: ZASP
Model Number: HA101
Payment & Shipping Terms:
Minimum Order Quantity: 2 pieces
Price: $1,199.00/pieces 2-499 pieces
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Contact Now

304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety

Description
Product Name: Automatic Bollard Material: 304 316 Stainless Steel
Application: Roadway Safety Height: 600mm~1000mm
Thickness: 6mm Diameter: 217mm
Voltage: Customer Required Certificate: CE ISO9001-2015
IP Rating: IP68 Warrenty: 1 Year
Highlight:

Automated Vehicle Rising Security Posts Barriers

,

Vehicle Rising Security Posts Barriers

,

Vehicle Impact Mitigation Automated Posts Barriers

Automated Vehicle Rising Security Posts Barriers For Vehicle Impact Mitigation
304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety 0
Professional Installation Guide for Automatic Rising Bollards
Site Assessment & Preparation
  • Survey the Area: Ensure level ground and verify no underground utilities are present
  • Mark the Area: Clearly mark bollard installation locations
  • Obtain Permits: Secure necessary local authority approvals and ensure regulatory compliance
Foundation Preparation
  • Excavation: Dig hole according to manufacturer specifications (typically 1.0-1.5m deep, 0.5-1m wide)
  • Install Drainage: Implement gravel or drain pipe systems to prevent water accumulation
Electrical & Control System Setup
  • Run Electrical Cables: Install underground conduit and wiring to bollard locations
  • Install Control Box: Position automation system in accessible, secure location
Bollard Installation
  • Place Bollard in Foundation: Carefully position and level the bollard
  • Connect Power & Controls: Wire according to manufacturer diagrams
  • Hydraulic Installation: Connect hydraulic lines for applicable models
Concrete Placement & Securing
  • Fill with Concrete: Pour concrete around bollard, avoiding moving parts
  • Allow to Set: Let concrete cure for 24-48 hours as specified
Testing & Calibration
  • Initial Power-Up: Test raising and lowering functionality
  • Adjust Settings: Calibrate sensors, timers, and access control integration
  • Emergency Features: Verify manual override systems operate correctly
Final Inspection & Safety
  • Inspection: Ensure all electrical connections are properly sealed
  • Security & Safety: Install warning lights, alarms, and appropriate signage
Maintenance Planning
Establish regular inspection and servicing schedule for hydraulic systems, sensors, and control mechanisms to ensure long-term reliability.
304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety 1
Product Specifications
Model NumberHA101-600
CertificationCE, IP 68, SGS
Dimensionφ400*1150mm
Bollard diameter217±1mm, customized for 271mm diameter
Bollard thickness6±1mm
Height above ground600mm, customized for 700-800-900-1000mm height
Rising time3.8s
Protection levelIP68
Working temperature-40℃ ~ +70℃
ColorCustomized
What are Hostile Vehicle Mitigation Barriers?
Hostile Vehicle Mitigation (HVM) barriers are physical security devices designed to prevent or mitigate the impact of deliberate vehicle attacks, including ramming attacks and unauthorized vehicle access to secured areas. These barriers are engineered to stop vehicles from breaching perimeters by either halting or slowing them down. HVM barriers protect high-risk sites, public spaces, critical infrastructure, and events from vehicle-borne threats.
304 316 Stainless Steel IP68 Rated Automatic Bollards with 600mm-1000mm Height for Roadway Safety 2
Why Choose ZASP?
ZASP is a professional manufacturer of HVM barriers and we are the ONLY Chinese supplier who passed the impact test in UK by MIRA.
We supply K4/K12 standard products including Shallow Mount Road Blockers, Fixed Bollards, Automatic Bollards, Removable Bollards, Rising Beam Gates, semi-automatic bollards, manual bollards, tyre killers, and modular vehicle barriers.
